型号Model 项目名称Name of part |
HF1000 |
HF2000 |
HF3000 |
HF4000 |
分离机滚筒直径mm Rotary Drum Diameter(mm) |
1000 |
1000 |
1250 |
1250 |
外置滚筛直径mm Rotary Drum Diameter(mm) |
---- |
800 |
1000 |
1250 |
筛分能力T/H Screening Capacity(t/h) |
20~30 |
30~40 |
40~50 |
50~60 |
分粗石尺寸 thick Stone Size Screened(mm) |
---- |
>Φ24 |
>Φ24 |
>Φ24 |
分离细石尺寸mm Small Stone Size Screened(mm) |
>Φ5~Φ13 |
>Φ5~Φ13 |
>Φ5~Φ13 |
>Φ5~Φ13 |
分离砂子尺寸mm Sand Size Screened(mm) |
Φ1~Φ5 |
Φ1~Φ5 |
Φ1~Φ5 |
Φ1~Φ5 |
电机总功率Kw General Power of motor(kw) |
6 |
13.5 |
15 |
15 |
分石机功率Kw Power of Stone Separator(kw) |
3 |
4 |
5.5 |
5.5 |
分砂机功率Kw Power of Sand Separator(kw) |
3 |
4 |
4 |
4 |
外置滚筛功率Kw Power of Rotary Drum |
--- |
5.5 |
5.5 |
7.5 |
总重量T Total Weight(t) |
* |
* |
* |
* |
外形尺寸m:(长×宽×高) Outline Dimension:(Lenghth×Width×Height) |
6200×1850×2200mm |
6200×1850×2200mm |
6200×2100×2450mm |
6200×2100×2450mm |
